TPSM82823SILR Integrated Circuit Chip 3A Step-Down Converter MicroSiP™ Power Module

TPSM82823SILR Integrated Circuit Chip 3A Step-Down Converter MicroSiP™ Power Module

Product Description Of TPSM82823SILR

TPSM82823SILR is 3A, step-down converter MicroSiP™ power modules optimized for small solution size and high efficiency. The power modules integrate a synchronous step-down converter and an inductor to simplify design, reduce external components and save PCB area.

Specification Of TPSM82823SILR

Features Of TPSM82823SILR

1.1-mm profile MicroSiP™ power module
CISPR 11 class B compliant
Up to 95% efficiency
2.4-V to 5.5-V input voltage range
0.6-V to 4-V adjustable output voltage
Fixed output voltages available: 1.2-V, 1.8-V, 2.5-V and 3.3-V
4-µA operating quiescent current
DCS-control topology
Power save mode option available for light load efficiency
Forced-PWM option available for CCM operation
100% duty cycle for lowest dropout
Hiccup short circuit protection
Output discharge
Power good output with window comparator
Integrated soft start-up
Overtemperature protection
2.0-mm × 2.5-mm × 1.1-mm 10-pin µSiL package
12 mm2 total solution size (for the fixed output voltage versions)

Applications Of TPSM82823SILR
Optical modules
Machine vision
Industrial PCs
PLCs
Wired Networking
