BES2000-IZ BT IC BT Audio SoC 40nm BT 2.1+4.2 Dual Mode System-On-Chip

BES2000-IZ BT IC BT Audio SoC 40nm BT 2.1+4.2 Dual Mode System-On-Chip​

Product Description Of BES2000-IZ

BES2000-IZ is a highly integrated single chip with BT 2.1+4.2 dual mode and high performance Cortex-M4F for audio and voice application. The path from the analog input through the hardware DSP core to the analog output is optimized for low latency and is ideal for AirBT*& noise cancelling headsets.
BES2000-IZ has been designed on highest level of integration to extremely reduce the number of external component. It is manufactured with advanced 40nm low power CMOS process and assembled with a 5.5*5.9mm BGA package.

Features Of BES2000-IZ

CMOS single-chip fully-integrated RF, PMU, BB, Audio and Cortex-M4F CPU
BT® v4.2 specification compliant
5-band fully configurable EQ
A2DP v1.3/AVRCP v1.5/HFP v1.5
Up to 300MHz ARM Cortex-M4F processor
4MB Serial Flash on-chip for custom program
Cortex M4 with on-chip boot-ROM and RAM
Security boot to protect customer IP
3.1V-5.5V input for VBAT
Internal LPO support for low power mode.
Support DCXO with internal oscillator circuit
BES AirBT Support
Dual MICs Noise reduction
Echo Cancellation
2 MICS Voice recognition support
2MICS for feed forward Active Noise
Cancellation
Multi-band EQ and Bass enhancement
Immersive audio with 3D or virtual surround sound
USB2.0 HS and USB compliant
Support Class H
Support Temperature Sensor
24bit audio processing
Support up to 96k x 24bit/192k x 16bit USB
Audio Playback
HiFi Stereo Audio DAC:
120dB SNR
110dB DNR
Sample Rates From 8 kHz to 384 kHz
HiFi Stereo Audio ADC: 96dB SNR
Sample Rates From 8 kHz to 384 kHz
Advanced 40nm low power process

Applications Of BES2000-IZ

High-end BT/WIFI dual mode speaker
Smart BT/WIFI music box
BT/WIFI docking station and soundbar
BT boom box
Other portable audio device
IOT platform
